Pet Food & Animal Feed
Pet Food Dryer
Product Type
Machine
High-efficiency Pet Food Dryer for rapid, uniform moisture reduction. Features multi-pass conveyor belts and precise thermal regulation.
VM Machines
Product Overview
Pet Food Dryer
Competitive price Pet Food Dryer, Customized dryer capacity 100-2000kg/h, Fast delivery, OEM service.
High efficiency Pet Food Dryer is a perfect solution in the drying process that we have created to help clients meet the rising need for improved pet food drying. This selection of dryers, impingement ovens, and hot-air circulation systems produces high-quality goods that are catered to your demands and has simple cleaning access. This high efficiency by-cross dryer can safely produce high-quality products at very high capacity while reducing product and energy waste.
Machine material:Stainless steel 304 or as customer’s request
Electricity component brand:Siemens,ABB motor available;Delta,LG inverter available
Burner brand:Baltur,Italy
Lead Time:10-15 days after receiving your deposit
Product Parameter:
|
Model |
VM5-3 |
VM5-5 |
VM8-5 |
VM8-7 |
VM11-7 |
|
Capacity(KG/H) |
100-200 |
200-300 |
300-400 |
400-600 |
800-1000 |
|
Layer quantity |
3 |
5 |
5 |
7 |
7 |
|
Belt width(mm) |
1000 |
1000 |
1000 |
1000 |
1000/1200 |
|
Belt length/layer(mm) |
5000 |
5000 |
8000 |
8000 |
11000 |
|
Electric heating Power(KW) |
36 |
54 |
70 |
90 |
120 |
|
Temperature |
50-120℃ |
50-120℃ |
50-120℃ |
50-120℃ |
50-120℃ |
|
Drying time(min) |
6-30 |
8-45 |
10-50 |
10-60 |
15-120 |
|
Dimension(M) |
5.5*1.2*1.8 |
5.5*1.2*2 |
8.5*1.2*2 |
8.5*1.2*2.2 |
11.5*1.2*2.2 |
We provide different heating method such as Gas heating, LPG heating, diesel heating or steam heating, and different capacity customized service.
Video
Application of the Pet Food Dryer:
This kind Pet food dryer is a low temperature dryer, which is mainly suitable for products that need to be dried at a lower temperature and longer drying time, such as pet food, dog food and cat food, fish feed and etc.
Features of Pet Food Dryer:
1.An effective solution to curing and drying problems of expanded aquatic feed,general particle feed and food.
2.Making the particles achieve desired water resistance and improve the appearance and output of particles.
3.Mesh with high-molecular polymer screen mesh or stainless steel stencil, perforated plate, non-stick material, clean and sanitary.
4.Unique air duct system, built-in circulation duct, can adjust the air flow direction according to the need, which can control the air flow between the materials.
5.Double-layer material drying, effective use of space, improve productivity, internal circulation hot air system, low energy consumption, low cost, good reliability.
6.There is no outer air pipes except the dehumidifying air pipe, thus the materials won’t be polluted and the heat efficiency and working condition are improved.
7.Precise control: the moisture uniformity controlled within ±0.5%.
8.Intelligent control system: one button startup, with functions such as water monitoring, energy consumption monitoring, fault query, production information query, etc.
9.Flexible configuration: steam and natural gas heat source can be selected to meet different needs.
10.All stainless steel 304 material structure, durable, easy to clean and maintain.
11.Adopt negative pressure moisture removal technology to effectively reduce odor.
12.The automatic ash removal device can timely eliminate the residual materials, safe and labor saving.
13.Easy control and operation: the air volume, heating temperature, material residence time and feed rate can be adjusted to achieve the desired drying effect
