Z Type Bucket Elevator
Looking for a Z Type Bucket Elevator? Specialized Z-shaped bucket elevator, essential for feeding fragile snacks into multihead weighers.
Capacity
3 - 8 cubic meters/hr
Bucket Material
Food Grade ABS / PP / SS
Shape
Z-Configuration
Bucket Action
Pendulum (Always Level)
Product Overview
The industry standard for feeding snack packaging machines. The 'Z' shape allows product to be loaded at ground level, lifted vertically, and then conveyed horizontally directly over the packaging machine's multihead weigher. The swinging buckets stay perfectly level until they hit the automated tipping point, ensuring zero product breakage.
Image Coming Soon
Engineering & Features
Z-shape configuration (Lower, Vertical, Upper horizontal)
Built for industrial reliability and 24/7 operation.
Swinging pendulum buckets (stay level)
Built for industrial reliability and 24/7 operation.
Zero-breakage gentle handling
Built for industrial reliability and 24/7 operation.
Multiple discharge point capability
Built for industrial reliability and 24/7 operation.
Applications & Output
- Potato Chips
- Fragile Extruded Snacks
- Kurkure
Technical Specifications
| Discharge | Pneumatic Multi-Point Tipping |
|---|---|
| Height | Customizable (Standard 3m-5m) |
| Frame | SS 304 |
| Vibratory Feeder | Included at Infeed |
Production Flow
Ground Infeed
Horizontal Travel
Vertical Lift
Horizontal Travel
Tipping Discharge
Z-Type Bucket Elevator for Fragile Snacks
The only choice for fragile snacks. Our Z-Elevators gently carry chips and puffs in pendulum buckets, ensuring zero breakage before they reach the packaging machine.
Product Gallery
Need Details For Z Type Bucket Elevator?
Share your requirement and our engineering team will help you choose the suitable machine configuration.
